  4. QYY- 2U MTP/MPO LC 288 Fibers Optic Patc
  • QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules
  • QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules
  • QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules
QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules

QYY- 2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules

  • Name:ODF 24 Ports 48 core LC UPC 1U fiber optical drawer patch panel
  • Connector: LC
  • Fiber Mode :G657A1; OM1; OM2; OM3; OM4
  • Connector B :LC/UPC; LC/APC Connector A :MPO/PC; MPO/APC; MTP/PC; MTP/APC
  • OTB,Fiber Termination Patch  , Fiber Distribution Unit Box,Optical cable terminal box
    Inquiry Send Email

    Description

    QYY-  2U MTP/MPO LC 288 Fibers Optic Patch Panel chassis 24 Modules


    Features:

    . 19" rack mount, Color black.

    . Baffles are used where adapters are not installed.
    . Reliability - 100% Tested.Factory terminated and tested.
    . Front cable management function:Cable can be routed to the front of

    . the cable management bar, either from the left or the right side.
    . Rear cable management function:Cable can be routed to the rear of the
    . cable management bar, from both sides.
    . 2U patch panel capacity comes up to 288F fully loaded , up to
    . 12 MPO/MTP® standard connectors.



    Ordering Information:

    roduct Description: 2U24MDD - SP - B - 9005 - 8×12MTP/PC - LC/UPC - OM3 - 1U
    1         2      3      4        5         6             7            8        9
    1 - Model 2U24MDD
    2 - Body Materials
    SP: SPCC(cold rolled steel sheet)
    3 - Painting Finish
    B: powder coat matt finish
    4 - Painting Color
    9005: RAL black
    5 - Patch cord Quantity
    8×12 : 8pcs of 12F ; 12×12: 12pc of 12F ; 4×24 : 4pc of 24F; 6×24 : 6pc of 24F
    6 - Connector A
    MPO/PC; MPO/APC; MTP/PC; MTP/APC
    7 - Connector B
    LC/UPC; LC/APC
    8 - Fiber Mode
    G657A1; OM1; OM2; OM3; OM4
    1U
    9- Panel Height
    Note:1. MP4-2U fully loaded with 144Fibers.

    2. Baffles are used where adapters are not installed.

    3. Empty frame w/o Adapters Description:OMP2-SP-B-9005-EM-1U



    Application:

    . Telecommunications subscriber loop
    . Fiber to the home (FTTH)
    . LAN/WAN
    . CATV
